Swimming Pool Filtration
Filtration group
Above-ground swimming pools filtration
For swimming pools up to 20m3 | 6-way valve| Prefilter
Filtration
Puissance 60W
Débit d'eau - 3,03m3/h
Warranty
Advantages
Why choose Poolex for the filtration of your above-ground swimming pool
Filtration group, compact, easy to install and use, no particular requirements.
This filtration group is a formidable ally for every owner of an above ground pool. Its integrated 60W pump comes with a tank that holds the filter media of your choice (sand, glass or Pureflow polymer filter ).
This model is perfectly suited to above ground swimming pools with a volume up to 20m3.
This 2 in 1 group ensures both pumping and filtration to maintain your swimming pool water clean and safe. Impurities are retained within the filtering media inside the tank. The filter is equipped with a pre-filter that retains excessively large particles avoiding any damage to the pump. Its multiport valve (6 way) supports several functions: self cleaning, filtration, drainage, rinse …
Sand Filter
The sand filter is the main element of the filtration group and consists of a tank that is compatible with all three types of filter media recommended to keep your swimming pool clean: quartz or glass sand, and Pureflow foam.
Capacity: 10kg of sand or 130g of Pureflow polymer filter.
Circulation Pump
The pump is discreetly imbedded into the base of the filter unit, including, however, a 60 W motor.
A pre-filter at the pump inlet retains large particles.
In contrast to filter units for small above-ground pools from larger manufacturers, this type of positioning makes the filter unit even more compact and allows it to be installed in the smallest of spaces.
6-way valve
The filter unit is equipped with a 6-way valve with all the functions necessary for a clean and performing swimming pool: filtration, backwash, rinsing, drainage, circulation and closed.
Pressure gauge
Essential to the filtration group, the pressure gauge shows at all time the filtration group state of clogging and its capacity to ensure its function./>
| Reference | JL-P11358FR | ||
|---|---|---|---|
| Power | 220-240V | ||
| Maximum water flow | 3.03 m³/h | ||
| Capacity | 60 W | ||
| Maximum operating pressure | < 0.2/> bar/psi | ||
| Efficient filtration surface | 0.058 m² | ||
| Maximum water temperature | 35°C | ||
| Recommended media | 5.5 kg | ||
| Quartz sand or glass No.20 | 17°C- 35°C | ||
| Recommended sand quantity | 10 kg | ||
| Homogeneous grain coefficient | >1.75 | ||
| Dimensions | 37x34x58 cm | ||
| Packaging dimensions | 37x37x47 cm | ||
| Net/gross weight | 5.5/6.7 kg |
